Description:

---

TRQ Fuel Pump Module Assembly Compatible with 2008-2011 Chevrolet Impala

Fuel Pump Module Assembly Fitment Compatible with: 2008-11 Chevrolet Impala V6 3.9L Product Attributes Outlet Outside Diameter: 0.35 in Outlet Quantity: 1 Average Current Draw: 11 A Voltage: 12 VDC Height: 12.24 in Housing Width: 125 mm Housing Length: 125 mm Top Mount Diameter: 129.5 mm Length: 182 mm Width: 227.5 mm Resistance Ohms Empty: 250 Ohms Height: 311 mm Terminal Quantity: 4 Housing Width: 4.92 in Housing Length: 4.92 in Resistance Ohms Full: 40 Ohms Minimum Flow Rating: 42.3 gph Average Flow Rating: 46.2 gph Top Mount Diameter: 5.12 in Maximum Flow Rating: 50.2 gph Minimum Pressure: 58 PSI Minimum Free Flow Rate: 63.4 gph Maximum Pressure: 63.8 PSI Length: 7.17 in Width: 8.98 in Outlet Outside Diameter: 9.49 mm Pump Type: Electric Connector Gender: Female Fuel Type: Gas In Tank or External: In Tank Internal Or External Strainer: Internal Terminal Gender: Male Fuel Tank Pressure Sensor Included: No Mounting Hardware Included: No Lock Ring Included: No Wire Harness Included: No Grade Type: Performance Terminal Type: Pin Housing Material: POM Plastic Outlet Type: Quick Connect Connector Shape: Race Track Universal Or Specific Fit: Specific Pump Design: Turbine Connector Color: White Negative Ground: Yes Strainer Included: Yes Fuel Sending Unit Included: Yes Fuel Filter Included: Yes Regulator Included: Yes Gasket Or Seal Included: Yes Product Features Complete Assembly: No modifications or assembly required Carbon Brush and Commutator: More than twice the service life compared to copper Flourine Rubber Seals: Resistant to high temperature, fuel, and solvents SAE J2044 Compliant: Improved mounting security, minimized installation error Reference Numbers Agility Autoparts: 4010686 Airtex: E3813M Carter: P76638M Delphi: FG0939 General Motors: 19257912 Spectra Premium: SP6621M US Motor Works: USEP3813M

Product Features

• TRQ products are covered by a 2-year / 24,000-mile warranty. Warranties cover the cost of products only and do not cover any damage, labor, or any other inconveniences incurred.
• Reference Number(s): 2,18,19,19,17,11,11,20,823,7,67534,A30010,A30212,A30393,A30520,A31006,B11112080TG,C0296M,C0308M,C0828M,D11113570TG,DFG0939,E3756M,E3786M,E3792M,E3796M,E3813M,FG0939,FP22051S,M100132,M100133,M100135,M100136,M10173,M10174,M3496238,M3520866,M3520871,MU1707,MU2164

---

---

Open Box Condition Notice:

Items are in perfect working condition. Items may have some minor signs of use, and the original protective wrapping may be absent or the item may be repackaged. All accessories will be included.

Return Policy:

You may return any item purchased within 30 days of receiving the shipment.
